Wheel-hub-bearing-unit-for-Chrysler Dodge Plymouth-512480

Wheel-hub-bearing-unit-for-Chrysler Dodge Plymouth-512480

FitVehicles/Application :Chrysler Dodge Plymouth-FIAT 500

AOZ NO:L-908

OE Numbers：512480

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

FitVehicles/Application :Chrysler Dodge Plymouth-FIAT 500

AOZ NO:L-908

OE Numbers：512480

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
ChryslerDodgePlymouth-512480

Fit Vehicles
FIAT
500	2012-2019

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: Can a bad hub bearing cause my speedometer to read incorrectly?

A: Yes. The speedometer uses wheel speed data from the ABS sensor. A damaged encoder ring can send inaccurate signals, causing the speedometer to fluctuate or display the wrong speed.

Q2: Why does my new hub have a small rubber plug on the back?

A: This plug seals the ABS sensor connector cavity during shipping to prevent moisture and debris from entering. Remove it before connecting the wiring harness.

Q3: Can I install a hub assembly without draining the differential fluid?

A: On most FWD and RWD vehicles, no fluid drain is needed. However, on some 4WD/AWD applications, removing the axle may require partial fluid drainage. Check your vehicle's service manual.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
