Fit Vehicles/Application:GM-USA-BUICK RENDEZVOUS,CHEVROLET VENTURE,OLDSMOBILE SILHOUETTE,PONTIAC AZTEK,MONTANA
AOZ NO:LD130
OE Numbers:513187
Cross Reference Numbers:
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
Fit Vehicles/Application:GM-USA-BUICK RENDEZVOUS,CHEVROLET VENTURE,OLDSMOBILE SILHOUETTE,PONTIAC AZTEK,MONTANA
AOZ NO:LD130
OE Numbers:513187
Cross Reference Numbers:
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
OEM-NUMBER | Cross Reference code |
GM-USA-513187 | |
Fit Vehicles | |
BUICK | |
RENDEZVOUS | 2002-2007 |
CHEVROLET | |
VENTURE | 2002-2004 |
OLDSMOBILE | |
SILHOUETTE | 2002-2004 |
PONTIAC | |
AZTEK | 2001-2005 |
MONTANA | 2001-2005 |
GENERAL PRODUCT DATA | |
Brand or Logo | AOZ or customer brand |
Place of Origin | China, Zhejiang |
Product Name | AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit |
Packing | White Box / Colour Box / Customized |
Certification | ISO/TS16949 - 2016 |
Sample | Available |
Delivery | Sea / Air / Land / Express |
Supply Ability | 10000 Piece / Per Month |
Port | Shanghai, Ningbo, Yiwu, Guangzhou |
ABS Sensor | Yes |
ACCURACY SPECIFICATIONS | |
Bearing materials | GCr15 = SAE52100 |
Flange materials | 55# Steel (High quality) |
Ball / roller materials | GCr15 = SAE52100 |
Cage materials | Top Grade PA66 + GF25 |
Seal materials | Stainless steel + NBR |
Wheel stud grade | 10.9 |
Bearing rings hardness control | 60-66 HRC |
Ball / roller hardness control | 61-66 HRC |
Inner and outer ring race max roughness control |
≤0.20μm |
Inner and outer ring race max roundness control |
≤3μm |
Product inspection | 100% |
Quality Guarantee | 2 years or 60,000 Kilometers |







FAQs
Q1: Why does my hub bearing make a noise that only appears when I drive over expansion joints?
A: Expansion joints create sudden vertical impacts that momentarily spike the load on the bearing. If the raceway has pitting or spalling, these impact loads can cause the rollers to bounce or chatter, producing a brief clunk or rattle that doesn't occur during smooth driving.
Q2: Why does my new hub have a small plastic cap over the center bore?
A: The cap protects the precision-machined bore surface from scratches, dirt, and corrosion during shipping and storage. Remove it before installing the axle shaft to ensure a proper fit.
Q3: Can a hub bearing failure cause my vehicle to make a noise that sounds like a loose muffler?
A: Yes. A severely worn bearing can produce a low-frequency rumbling or rattling sound that resonates through the chassis, mimicking the sound of a loose exhaust component. Check for bearing play before inspecting the exhaust system.
