Wheel-hub-bearing-unit-for-GM-USA-515144

Wheel-hub-bearing-unit-for-GM-USA-515144

Fit Vehicles/Application:GM-USA-Chevrolet Silverado 2500/3500,GMC Sierra 2500/3500

AOZ NO:LD155

OE Numbers:515144

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles/Application:GM-USA-Chevrolet Silverado 2500/3500,GMC Sierra 2500/3500

AOZ NO:LD155

OE Numbers:515144

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
GM-USA-515144

Fit Vehicles
Chevrolet
Silverado 2500/3500	2011-2019
GMC
Sierra 2500/3500	2011-2019

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: Why does my hub bearing make a noise that only appears when the vehicle is turning right and accelerating?

A: Turning right shifts weight onto the left bearing, while acceleration adds torque load. The combination of lateral and torque loads on a damaged left bearing amplifies the noise significantly.

Q2: Why does my new hub have a small rubber bumper on the ABS wire clip?

A: The rubber bumper prevents the wire clip from vibrating against the knuckle or suspension components, which could cause wire fatigue or chafing over time.

Q3: Can a hub bearing failure cause my vehicle to make a noise that sounds like a failing differential?

A: Yes. Both can produce a whining or grinding sound that changes with vehicle speed. To differentiate, check whether the noise changes with turning (hub bearing) or remains constant regardless of steering input (differential).

“Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
