wheel hub bearing unit forBYD-EG-3502401\EG-3502402\DAC45830042\BYD-F6-G6-FRONT\DWH01336\BYD-EG3502401/402\DAC45830042\W4583

Fit Vehicles /Application : BYD F6, BYD G6 Front Wheel Hub Bearing

AOZ NO:LD698

OE Numbers:EG-3502401 (Left), EG-3502402 (Right), DAC45830042

Cross Reference Numbers:VKBA7202, R17666, 9219216K, 713611489

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application : BYD F6, BYD G6 Front Wheel Hub Bearing

AOZ NO:LD698

OE Numbers:EG-3502401 (Left), EG-3502402 (Right), DAC45830042

Cross Reference Numbers:VKBA7202, R17666, 9219216K, 713611489

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
BYD---EG-3502401	SKF:VKBA7202
EG-3502402	SNR:R17666
DAC45830042	GSP:9219216K
BYD-F6-G6-FRONT	NTN:WBK17118
DWH01336	FAG:713611489
BYD-EG3502401/402	FEBI BILSTEIN:172991
DAC45830042	MOOG:SA-WB-12296
W4583	OPTIMAL:964496

Fit Vehicles
BYD
F6 Front Wheel	2008–2014
G6 Front Wheel	2011–2018

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: How can I test the ABS encoder ring without a scanner?

A: You can use a small metal object (like a paperclip). It should be magnetically attracted to the seal edge where the encoder ring is located.

Q2: Can a bad hub cause the traction control light to come on?

A: Yes. Since the hub provides wheel speed data, a faulty encoder ring can confuse the traction control system and trigger the warning light.

Q3: How do I check if the hub is overheating after a drive?

A: Use an infrared thermometer on the hub face. If it is significantly hotter than the other wheels, it indicates excessive friction or improper installation.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
