wheel hub bearing unit forBYD-MEH-3104100\MEH3104100\DAC45840042ABS\SL930317\MEW-3104100\RM930182

Fit Vehicles /Application :BYD YUAN, SONG MAX

AOZ NO:LD1483

OE Numbers:MEH-3104100, MEH3104100, DAC45840042ABS, SL930317

Cross Reference Numbers:DAC45840042ABS, SL930317, MEW-3104100, RM930182

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application :BYD YUAN, SONG MAX

AOZ NO:LD1483

OE Numbers:MEH-3104100, MEH3104100, DAC45840042ABS, SL930317

Cross Reference Numbers:DAC45840042ABS, SL930317, MEW-3104100, RM930182

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
BYD---MEH-3104100	A.B.S.: 201625
MEH3104100	SKF: VKBA7432
DAC45840042ABS	GSP: 9219400K
SL930317	SNR: R17850
MEW-3104100	FAG: 713611673
RM930182	FEBI BILSTEIN: 173175

Fit Vehicles
BYD
YUAN（Rear Left）	2016 - 2019
SONG MAX（Rear Left）	2017 - 2021

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: How can I test the ABS encoder ring without a scanner?

A: You can use a small metal object (like a paperclip). It should be magnetically attracted to the seal edge where the encoder ring is located.

Q2: Can a bad hub cause the traction control light to come on?

A: Yes. Since the hub provides wheel speed data, a faulty encoder ring can confuse the traction control system and trigger the warning light.

Q3: How do I check if the hub is overheating after a drive?

A: Use an infrared thermometer on the hub face. If it is significantly hotter than the other wheels, it indicates excessive friction or improper installation.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
