wheel hub bearing unit forBYD-TIG-3104100\TIG3104100\DAC54960052ABS\SL930496\TIGW-3104100\RM930202

Fit Vehicles /Application :BYD DENZA D9 EV New Model

AOZ NO:LD1485

OE Numbers:TIG-3104100, TIG3104100, DAC54960052ABS, SL930496

Cross Reference Numbers:DAC54960052ABS, SL930496, TIGW-3104100, RM930202

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application :BYD DENZA D9 EV New Model

AOZ NO:LD1485

OE Numbers:TIG-3104100, TIG3104100, DAC54960052ABS, SL930496

Cross Reference Numbers:DAC54960052ABS, SL930496, TIGW-3104100, RM930202

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
BYD---TIG-3104100	A.B.S.: 201637
TIG3104100	SKF: VKBA7452
DAC54960052ABS	GSP: 9219416K
SL930496	SNR: R17866
TIGW-3104100	FAG: 713611689
RM930202	FEBI BILSTEIN: 173191

Fit Vehicles
DENZA
D9 EV	2022 - 2026
D9 DM-i	2022 - 2026

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: How should I store hub units in my warehouse?

A: Store them horizontally in a clean, dry, and climate-controlled environment. Avoid stacking them too high to prevent deformation of the bottom units.

Q2: Can a sealed hub unit expire?

A: The unit itself doesn't expire, but the grease can degrade over many years if stored in extreme heat or direct sunlight. Proper storage ensures it remains ready for installation.

Q3: Do I need to rotate the bearings during long-term storage?

A: No, modern sealed units do not require rotation during storage. Just keep them away from strong magnetic fields to protect the ABS encoder.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
