wheel hub bearing unit forGEELY-EC8-3104101\EC83104101\DAC2F74R4520A\SL930636R\EC8-RH-REAR-ABS\DWH01244R\DAC40740045ABS-R\W4074-R

Fit Vehicles /Application :GEELY EMGRAND EC8, RH Rear Wheel With ABS

AOZ NO：LD665

OE Numbers:EC8-3104101, EC83104101, DAC2F74R4520A, SL930636R

Cross Reference Numbers:VKBA6923, R17441, 9218075K, 713611171

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application :GEELY EMGRAND EC8, RH Rear Wheel With ABS

AOZ NO：LD665

OE Numbers:EC8-3104101, EC83104101, DAC2F74R4520A, SL930636R

Cross Reference Numbers:VKBA6923, R17441, 9218075K, 713611171

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
GEELY---EC8-3104101	SKF:VKBA6923
EC83104101	SNR:R17441
DAC2F74R4520A	GSP:9218075K
SL930636R	NTN:WBK17033
EC8-RH-REAR-ABS	FAG:713611171
DWH01244R	FEBI BILSTEIN:172315
DAC40740045ABS-R	MOOG:SA-WB-12023
W4074-R	OPTIMAL:964029

Fit Vehicles
GEELY
EMGRAND EC8 RH Rear With ABS	2010–2017

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: Can I just replace the bearing inside the hub assembly?

A: No. Modern hub units are factory-assembled as a single sealed unit. Attempting to press out and replace the internal bearing will destroy the precision clearances and seals. The entire assembly must be replaced.

Q2: Is it okay to use an impact wrench to tighten the axle nut?

A: Never. Impact wrenches can easily over-torque the nut, stretching the stud or crushing the bearing. Always use a calibrated torque wrench to apply the exact manufacturer-specified torque.

Q3: Do I need to replace the ABS sensor if I replace the hub?

A: Not necessarily. If the ABS sensor is functioning perfectly and the wiring is intact, you can reuse it. However, since the magnetic encoder is built into the new hub, the system will read the speed from the hub itself.
