wheel hub bearing unit forSGMW- 23968156\DAC46840043ABS\SL930640\NEW-CAPTIVA-BAOJUN730-REAR-ABS\DWH01304\SGMW-23968156\DAC46840043ABS\W4684-ABS

Fit Vehicles /Application : SGMW-CHEVROLET New Captiva 1.5T, BAOJUN 730 (New Model Independent Suspension) Rear Wheel With ABS

AOZ NO:LD1517

OE Numbers:23968156, DAC46840043ABS, SL930640

Cross Reference Numbers:VKBA7162, R17634, 9219184K, 713611457

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application : SGMW-CHEVROLET New Captiva 1.5T, BAOJUN 730 (New Model Independent Suspension) Rear Wheel With ABS

AOZ NO:LD1517

OE Numbers:23968156, DAC46840043ABS, SL930640

Cross Reference Numbers:VKBA7162, R17634, 9219184K, 713611457

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
SGMW--- 23968156	SKF:VKBA7162
DAC46840043ABS	SNR:R17634
SL930640	GSP:9219184K
NEW-CAPTIVA-BAOJUN730-REAR-ABS	NTN:WBK17094
DWH01304	FAG:713611457
SGMW-23968156	FEBI BILSTEIN:172959
DAC46840043ABS	MOOG:SA-WB-12264
W4684-ABS	OPTIMAL:964464

Fit Vehicles
BAOJUN
730 (Independent Rear Suspension) Rear With ABS	2019–2024
CHEVROLET
New Captiva 1.5T Rear With ABS	2019–2025

Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: How does hitting potholes affect the wheel hub?

A: Severe impacts can cause micro-fractures in the bearing raceways or deform the flange, leading to premature wear and vibration.

Q2: Does towing heavy loads shorten the hub's lifespan?

A: Yes. Towing significantly increases the axial and radial loads on the bearings, accelerating wear and requiring more frequent inspections.

Q3: Is it safe to drive through deep water with a new hub?

A: While our seals are highly resistant, driving through deep water causes rapid temperature changes that can compromise the seal over time. Inspect them afterward.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
