204001454AA wheel hub bearing unit for CHERY

204001454AA wheel hub bearing unit for CHERY

Fit Vehicles /Application :Chery Tiggo 7 Pro 1 2019-. (T1E) ，Tiggo 8 Pro 1 2021- (T1D)

AOZ NO：LD1544

OE Numbers: 204001454AA

Cross Reference Numbers: 976201

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application :Chery Tiggo 7 Pro 1 2019-. (T1E) ，Tiggo 8 Pro 1 2021- (T1D)

AOZ NO：LD1544

OE Numbers: 204001454AA

Cross Reference Numbers: 976201

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER：	Cross Reference code
CHERY204001454AA	BRTEC:976201
	BLUE PRINT:ADN18260
	FEDERAL MOGUL:NIWB12160
	HERTH+BUSS JAKOPARTS:J4710245
	KAVO PARTS:WBH7213
	METZGER:WM 2452
	MOOG:NIWB12160
	NIPPARTS:N4710187
	OPTIMAL:963145

Fit Vehicles
CHERY
EXEEDTXL	20212025
TIGGO7 PROMAX	20222026
TIGGO8PRO	20202025

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: Can you manufacture products based on our specific drawings or samples?

A: Yes, we specialize in OEM and ODM services. We can develop molds and produce units strictly according to your technical drawings or physical samples.

Q2: What certifications do your wheel hub units hold?

A: Our products are certified with ISO9001 and IATF16949 quality management systems. We can also provide specific test reports upon request for different markets.

Q3: Do you offer a warranty for your products?

A: Typically, we offer a 12-month or 20,000-kilometer warranty (whichever comes first) against manufacturing defects, provided the product is installed and used correctly.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
