Wheel-hub-bearing-unit-for-BAIC-113104010

Fit Vehicles /Application :BAIC-E130/E150,SENOVAD20/X25

AOZ NO:LD769

OE Numbers:113104010

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

EMAIL

Fit Vehicles /Application :BAIC-E130/E150SENOVAD20/X25

AOZ NO:LD769

OE Numbers:113104010

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER

Cross Reference code

BAIC-113104010






Fit Vehicles


SENOVA


D20

2014-2017

X25

2016-2019

BAIC


E130

2012-2014

E150

2012-2014

GENERAL PRODUCT DATA

Brand or Logo

AOZ or customer brand

Place of Origin

China, Zhejiang



Product Name

AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit

Packing

White Box / Colour Box / Customized

Certification

ISO/TS16949 - 2016

Sample

Available

Delivery

Sea / Air / Land / Express

Supply Ability

10000 Piece / Per Month

Port

Shanghai, Ningbo, Yiwu, Guangzhou

ABS Sensor

Yes





ACCURACY SPECIFICATIONS

Bearing materials

GCr15 = SAE52100

Flange materials

55# Steel (High quality)

Ball / roller materials

GCr15 = SAE52100

Cage materials

Top Grade PA66 + GF25

Seal materials

Stainless steel + NBR

Wheel stud grade

10.9

Bearing rings hardness control

60-66 HRC

Ball / roller hardness control

61-66 HRC

Inner and outer ring race max roughness control



≤0.20μm

Inner and outer ring race max roundness control



≤3μm

Product inspection

100%

Quality Guarantee

2 years or 60,000 Kilometers















FAQs

Q1: Can a bad hub assembly cause my car to fail a safety inspection?

A: Yes. Most safety inspections check for excessive wheel bearing play and functional ABS systems. A failing hub will result in an automatic failure.



Q2: Is it normal for the new hub to feel warm after a short test drive?

A: Yes. New hubs contain thick factory grease that creates initial friction. It is normal for the hub to feel warm, but it should not be scorching hot. If it is too hot to touch, the axle nut may be over-torqued.



Q3: What happens if I forget to plug in the ABS sensor wire?

A: The vehicle will drive normally, but the ABS and traction control warning lights will illuminate. The anti-lock braking feature will be disabled until the connector is properly seated.

"Quality First, Customers First",  "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
