Wheel-hub-bearing-unit-for-Brilliance Auto-3496008

Wheel-hub-bearing-unit-for-Brilliance Auto-3496008

Fit Vehicles /Application :Brilliance Auto-SplendorFRV/FSV/CROSS/H320/H530/H330/V5

AOZ NO:L-018

OE Numbers:3496008

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application :Brilliance Auto-SplendorFRV/FSV/CROSS/H320/H530/H330/V5

AOZ NO:L-018

OE Numbers:3496008

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
Brilliance Auto-3496008

Fit Vehicles
Splendor
FRV	2007-2012
FSV	2010-2014
CROSS	2010-2014
H320	2012-2015
H530	2013-2017
H330	2011-2017
V5	2011-2017

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: Can a bad wheel hub cause my vehicle to pull to one side?

A: Yes. Excessive play or uneven friction in a failing hub can alter the wheel's tracking, causing the vehicle to pull to one side and making steering feel unstable.

Q2: Why does the ABS light turn on after I install a new hub?

A: The most common reason is that the ABS sensor is too far from the new magnetic encoder ring, or the hub was installed backwards. It can also mean the sensor wire was accidentally pinched during installation.

Q3: Is it safe to drive with a loose axle nut?

A: Absolutely not. A loose axle nut allows the wheel to wobble on the hub, which will rapidly destroy the new bearing, ruin the brake rotor, and could cause the wheel to detach while driving.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
