Wheel-hub-bearing-unit-for-DFM-E240310J-D0200\E240310JD0200

Fit Vehicles /Application :DFM-AEOLUS-AX7

AOZ NO:LD729

OE Numbers:E240310J-D0200,E240310JD0200

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application :DFM-AEOLUS-AX7

AOZ NO:LD729

OE Numbers:E240310J-D0200,E240310JD0200

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
DFM-E240310J-D0200
E240310JD0200

Fit Vehicles
DFM
AEOLUS-AX7	2014-2019

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: Do I need to align the wheels after replacing a hub assembly?

A: Yes. Replacing a hub can alter suspension geometry slightly. An alignment is recommended to prevent uneven tire wear and ensure proper steering return.

Q2: Can I install a hub assembly without cleaning the knuckle surface?

A: No. Rust or debris on the mounting surface will cause runout (wobble), leading to vibration and premature failure. Always clean the surface to bare metal before installation.

Q3: Does the new hub come with pre-applied grease?

A: Yes, modern hub units are sealed and pre-greased for life. Do not attempt to add extra grease or open the seals, as this will contaminate the bearing internals.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
