Fit Vehicles /Application :FOTON-Toano
AOZ NO:LD776
OE Numbers:V1300180001A0
Cross Reference Numbers:
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
Fit Vehicles /Application :FOTON-Toano
AOZ NO:LD776
OE Numbers:V1300180001A0
Cross Reference Numbers:
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
OEM-NUMBER | Cross Reference code |
FOTON-V1300180001A0 | |
Fit Vehicles | |
FOTON | |
Toano | 2020-Present |
GENERAL PRODUCT DATA | |
Brand or Logo | AOZ or customer brand |
Place of Origin | China, Zhejiang |
Product Name | AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit |
Packing | White Box / Colour Box / Customized |
Certification | ISO/TS16949 - 2016 |
Sample | Available |
Delivery | Sea / Air / Land / Express |
Supply Ability | 10000 Piece / Per Month |
Port | Shanghai, Ningbo, Yiwu, Guangzhou |
ABS Sensor | Yes |
ACCURACY SPECIFICATIONS | |
Bearing materials | GCr15 = SAE52100 |
Flange materials | 55# Steel (High quality) |
Ball / roller materials | GCr15 = SAE52100 |
Cage materials | Top Grade PA66 + GF25 |
Seal materials | Stainless steel + NBR |
Wheel stud grade | 10.9 |
Bearing rings hardness control | 60-66 HRC |
Ball / roller hardness control | 61-66 HRC |
Inner and outer ring race max roughness control |
≤0.20μm |
Inner and outer ring race max roundness control |
≤3μm |
Product inspection | 100% |
Quality Guarantee | 2 years or 60,000 Kilometers |
FAQs
Q1: Can I use anti-seize on the hub mounting surface?
A: Yes, but use it sparingly. A very thin layer prevents future rust, but too much can alter the seating position and cause vibration.
Q2: How do I know if my hub has an integrated ABS sensor?
A: Integrated hubs have a built-in magnetic encoder ring on the inner seal and often include a wiring harness connector.
Q3: What happens if I over-torque the axle nut?
A: Over-torquing crushes the internal bearing rollers, eliminating clearance. This creates extreme heat and causes the new hub to fail quickly.
"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
