Wheel-hub-bearing-unit-for-GM-USA-512308

Fit Vehicles/Application:GM-USA-BUICK TERRAZA,CHEVROLET UPLANDER,PONTIAC MONTANA

AOZ NO:L-934

OE Numbers:512308

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

EMAIL

Fit Vehicles/Application:GM-USA-BUICK TERRAZACHEVROLET UPLANDERPONTIAC MONTANA

AOZ NO:L-934

OE Numbers:512308

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER

Cross Reference code

GM-USA-512308





Fit Vehicles


BUICK


TERRAZA

2006-2007

CHEVROLET


UPLANDER

2006-2009

PONTIAC


MONTANA

2006-2009

GENERAL PRODUCT DATA

Brand or Logo

AOZ or customer brand

Place of Origin

China, Zhejiang



Product Name

AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit

Packing

White Box / Colour Box / Customized

Certification

ISO/TS16949 - 2016

Sample

Available

Delivery

Sea / Air / Land / Express

Supply Ability

10000 Piece / Per Month

Port

Shanghai, Ningbo, Yiwu, Guangzhou

ABS Sensor

Yes



ACCURACY SPECIFICATIONS

Bearing materials

GCr15 = SAE52100

Flange materials

55# Steel (High quality)

Ball / roller materials

GCr15 = SAE52100

Cage materials

Top Grade PA66 + GF25

Seal materials

Stainless steel + NBR

Wheel stud grade

10.9

Bearing rings hardness control

60-66 HRC

Ball / roller hardness control

61-66 HRC

Inner and outer ring race max roughness control



≤0.20μm

Inner and outer ring race max roundness control



≤3μm

Product inspection

100%

Quality Guarantee

2 years or 60,000 Kilometers
















FAQs

Q1: Why does my hub make a clicking noise that only appears when turning sharply at low speed?

A: Sharp turns place maximum lateral load on the bearing. If the rollers or raceway have localized damage, this load can cause a clicking sound as the damaged surfaces make contact.


Q2: Why does my new hub have a small metal retaining ring visible inside the center bore?

A: This ring is part of the internal bearing assembly and helps maintain the correct positioning of the bearing components. It should not be removed or disturbed during installation.


Q3: Can a hub bearing failure cause my vehicle to make a noise that sounds like a helicopter?

A: Yes. A severely worn bearing can produce a rhythmic chopping or thumping sound that resembles helicopter blades, especially at highway speeds. This indicates advanced internal damage.

“Quality First, Customers First",  "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
