Wheel-hub-bearing-unit-for-GM-USA-515091

Wheel-hub-bearing-unit-for-GM-USA-515091

Fit Vehicles/Application:GM-USA-Chevrolet: Astro ,GMC: SaFWari

AOZ NO:LD097

OE Numbers:515091

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles/Application:GM-USA-Chevrolet: Astro ,GMC: SaFWari

AOZ NO:LD097

OE Numbers:515091

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
GM-USA-515091

Fit Vehicles
Chevrolet
Astro	2003-2005
GMC
SaFWari	2003-2005

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: Can cold weather make a hub bearing noise worse?

A: Yes. Cold temperatures cause the grease inside the bearing to thicken, which can amplify existing noise from a worn bearing. The noise may temporarily improve as the bearing warms up during driving.

Q2: Why does my steering wheel vibrate only when the brakes are applied?

A: Hub runout transfers to the brake rotor, causing it to wobble slightly. When the brake pads clamp down on the uneven rotor surface, the vibration is transmitted through the brake pedal and steering wheel.

Q3: Can I install a hub assembly with an impact wrench?

A: You can use an impact wrench to snug the bolts, but the final torque must always be applied with a calibrated torque wrench. Impact tools do not provide accurate torque readings and can easily over-torque fasteners.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
