Wheel-hub-bearing-unit-for-GM-USA-515104

Wheel-hub-bearing-unit-for-GM-USA-515104

Fit Vehicles/Application:GM-USA-Chevrolet Colorado,GMC Canyon,Isuzu I-280, I-290, I-370

AOZ NO:LD082

OE Numbers:515104

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles/Application:GM-USA-Chevrolet Colorado,GMC Canyon,Isuzu I-280, I-290, I-370

AOZ NO:LD082

OE Numbers:515104

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
GM-USA-515104

Fit Vehicles
Chevrolet
Colorado	2004-Present
GMC
Canyon	2004-Present
Isuzu
I-280	2006
I-290	2007-2008
I-370	2007-2008

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: What causes a hub to make a grinding noise that gets louder with speed?

A: This indicates severe internal damage where the bearing rollers or raceways are deteriorating. The grinding is metal-on-metal contact that worsens as the bearing continues to fail.

Q2: Can a hub bearing failure cause my vehicle to make a clunking noise over bumps?

A: Yes. Excessive play allows the hub to shift under load changes, creating a clunking sound when the suspension compresses or extends over road irregularities.

Q3: Why does my new hub have a protective cap over the center?

A: This cap protects the bearing seals and ABS encoder ring from damage during shipping and handling. Remove it only when ready to install the axle shaft.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed
