Fit Vehicles /Application :JMC-LANDWIND X5
AOZ NO:LD798
OE Numbers:LF6460QS-MA,LF6460QSMA
Cross Reference Numbers:
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
Fit Vehicles /Application :JMC-LANDWIND X5
AOZ NO:LD798
OE Numbers:LF6460QS-MA,LF6460QSMA
Cross Reference Numbers:
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
OEM-NUMBER | Cross Reference code |
JMC-LF6460QS-MA | |
LF6460QSMA |
Fit Vehicles | |
JMC | |
LANDWIND X5 | 2013-Present |
GENERAL PRODUCT DATA | |
Brand or Logo | AOZ or customer brand |
Place of Origin | China, Zhejiang |
Product Name | AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit |
Packing | White Box / Colour Box / Customized |
Certification | ISO/TS16949 - 2016 |
Sample | Available |
Delivery | Sea / Air / Land / Express |
Supply Ability | 10000 Piece / Per Month |
Port | Shanghai, Ningbo, Yiwu, Guangzhou |
ABS Sensor | Yes |
ACCURACY SPECIFICATIONS | |
Bearing materials | GCr15 = SAE52100 |
Flange materials | 55# Steel (High quality) |
Ball / roller materials | GCr15 = SAE52100 |
Cage materials | Top Grade PA66 + GF25 |
Seal materials | Stainless steel + NBR |
Wheel stud grade | 10.9 |
Bearing rings hardness control | 60-66 HRC |
Ball / roller hardness control | 61-66 HRC |
Inner and outer ring race max roughness control |
≤0.20μm |
Inner and outer ring race max roundness control |
≤3μm |
Product inspection | 100% |
Quality Guarantee | 2 years or 60,000 Kilometers |
FAQs
Q1: Can water damage a sealed hub?
A: Yes. Deep water or high-pressure washing can force moisture past the seals, washing out the grease and causing internal rust.
Q2: Why does the ABS light turn on after a new installation?
A: The hub is likely installed backwards, or the sensor wire was pinched during installation. The sensor cannot read the magnetic ring.
Q3: Is it safe to drive with a loose axle nut?
A: Absolutely not. A loose nut allows the wheel to wobble, which will rapidly destroy the new bearing and could cause the wheel to detach.
