Wheel-hub-bearing-unit-for-Zotye-3104200-A01

Fit Vehicles /Application :Zotye-Z300/Z500/DOMY X5, LH

AOZ NO:LD1465

OE Numbers:3104200-A01

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

EMAIL

Fit Vehicles /Application :Zotye-Z300/Z500/DOMY X5, LH

AOZ NO:LD1465

OE Numbers:3104200-A01

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER

Cross Reference code

Zotye-3104200-A01






Fit Vehicles


Zotye


Z300

2012-2016

Z500

2014-2017

DOMY


X5

2015-2018

GENERAL PRODUCT DATA

Brand or Logo

AOZ or customer brand

Place of Origin

China, Zhejiang



Product Name

AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit

Packing

White Box / Colour Box / Customized

Certification

ISO/TS16949 - 2016

Sample

Available

Delivery

Sea / Air / Land / Express

Supply Ability

10000 Piece / Per Month

Port

Shanghai, Ningbo, Yiwu, Guangzhou

ABS Sensor

Yes





ACCURACY SPECIFICATIONS

Bearing materials

GCr15 = SAE52100

Flange materials

55# Steel (High quality)

Ball / roller materials

GCr15 = SAE52100

Cage materials

Top Grade PA66 + GF25

Seal materials

Stainless steel + NBR

Wheel stud grade

10.9

Bearing rings hardness control

60-66 HRC

Ball / roller hardness control

61-66 HRC

Inner and outer ring race max roughness control



≤0.20μm

Inner and outer ring race max roundness control



≤3μm

Product inspection

100%

Quality Guarantee

2 years or 60,000 Kilometers















FAQs

Q1: Why is it dangerous to store new hub assemblies near strong magnets or electric motors?

A: Hubs with integrated ABS sensors contain a delicate magnetic encoder ring. Storing them near strong magnetic fields can demagnetize or scramble the ring, rendering the ABS sensor useless before it's even installed.



Q2: Can a bad wheel bearing cause my car to fail a safety inspection?

A: Yes. Safety inspections check for excessive wheel play and functional ABS systems. A failing hub will result in an automatic failure.



Q3: Is it normal for the new hub to feel warm after a short test drive?

A: Yes. New hubs contain thick factory grease that creates initial friction. It is normal for the hub to feel warm, but it should not be scorching hot.

"Quality First, Customers First",  "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
