Fit Vehicles /Application :BYD QIN PRO
AOZ NO:LD1489
OE Numbers:HAD-3103100, HAD3103100, DAC48840046ABS, SL931024
Cross Reference Numbers:DAC48840046ABS, SL931024, HADW-3103100, RM930226
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
Fit Vehicles /Application :BYD QIN PRO
AOZ NO:LD1489
OE Numbers:HAD-3103100, HAD3103100, DAC48840046ABS, SL931024
Cross Reference Numbers:DAC48840046ABS, SL931024, HADW-3103100, RM930226
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
OEM-NUMBER | Cross Reference code |
BYD---HAD-3103100 | A.B.S.: 201661 |
HAD3103100 | SKF: VKBA7492 |
DAC48840046ABS | GSP: 9219448K |
SL931024 | SNR: R17898 |
HADW-3103100 | FAG: 713611721 |
RM930226 | FEBI BILSTEIN: 173223 |
Fit Vehicles | |
QIN | |
PRO DM | 2019 - 2022 |
PRO EV | 2019 - 2022 |
PRO DM-i | 2020 - 2022 |
GENERAL PRODUCT DATA | |
Brand or Logo | AOZ or customer brand |
Place of Origin | China, Zhejiang |
Product Name | AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit |
Packing | White Box / Colour Box / Customized |
Certification | ISO/TS16949 - 2016 |
Sample | Available |
Delivery | Sea / Air / Land / Express |
Supply Ability | 10000 Piece / Per Month |
Port | Shanghai, Ningbo, Yiwu, Guangzhou |
ABS Sensor | Yes |
ACCURACY SPECIFICATIONS | |
Bearing materials | GCr15 = SAE52100 |
Flange materials | 55# Steel (High quality) |
Ball / roller materials | GCr15 = SAE52100 |
Cage materials | Top Grade PA66 + GF25 |
Seal materials | Stainless steel + NBR |
Wheel stud grade | 10.9 |
Bearing rings hardness control | 60-66 HRC |
Ball / roller hardness control | 61-66 HRC |
Inner and outer ring race max roughness control |
≤0.20μm |
Inner and outer ring race max roundness control |
≤3μm |
Product inspection | 100% |
Quality Guarantee | 2 years or 60,000 Kilometers |
FAQs
Q1: Do you provide torque specifications?
A: Yes. Every product includes a technical sheet with exact axle nut and flange bolt torque values.
Q2: Can your engineers help diagnose complex issues?
A: Absolutely. Our technical team can guide your mechanics through diagnostic steps to find the root cause.
Q3: Do you offer installation training videos?
A: Yes. We provide a library of professional installation videos covering various hub types and vehicle platforms.
