$wheel hub bearing unit forBYD-HAEV-3104100 / HAEV-3104100/E5H\DAC46840044ABS\SL931218\BYD-E5-E5H-REAR-ABS\DWH01472\BYD-HAEV-3104100\DAC46840044ABS\W4684-ABS$ $wheel hub bearing unit forBYD-HAEV-3104100 / HAEV-3104100/E5H\DAC46840044ABS\SL931218\BYD-E5-E5H-REAR-ABS\DWH01472\BYD-HAEV-3104100\DAC46840044ABS\W4684-ABS$ $wheel hub bearing unit forBYD-HAEV-3104100 / HAEV-3104100/E5H\DAC46840044ABS\SL931218\BYD-E5-E5H-REAR-ABS\DWH01472\BYD-HAEV-3104100\DAC46840044ABS\W4684-ABS$

wheel hub bearing unit forBYD-HAEV-3104100 / HAEV-3104100/E5H\DAC46840044ABS\SL931218\BYD-E5-E5H-REAR-ABS\DWH01472\BYD-HAEV-3104100\DAC46840044ABS\W4684-ABS

Fit Vehicles /Application : BYD E5 (EV, E5H version) Rear Wheel Hub Bearing With ABS

AOZ NO:LD1477

OE Numbers:HAEV-3104100, HAEV-3104100/E5H, DAC46840044ABS, SL931218

Cross Reference Numbers:VKBA7372, R17802, 9219352K, 713611625

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application : BYD E5 (EV, E5H version) Rear Wheel Hub Bearing With ABS

AOZ NO:LD1477

OE Numbers:HAEV-3104100, HAEV-3104100/E5H, DAC46840044ABS, SL931218

Cross Reference Numbers:VKBA7372, R17802, 9219352K, 713611625

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
BYD--HAEV-3104100 / HAEV-3104100/E5H	SKF:VKBA7372
DAC46840044ABS	SNR:R17802
SL931218	GSP:9219352K
BYD-E5-E5H-REAR-ABS	NTN:WBK17220
DWH01472	FAG:713611625
BYD-HAEV-3104100	FEBI BILSTEIN:173127
DAC46840044ABS	MOOG:SA-WB-12432
W4684-ABS	OPTIMAL:964632

Fit Vehicles
BYD
E5 (E5H version)	2016–2020

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: Do you perform road tests on your hub units?

A: Yes. In addition to dynamometer testing, we conduct real-world road tests on various vehicle platforms to validate noise levels, handling, and durability under actual driving conditions.

Q2: How do you test the hub's resistance to shock loads?

A: We use specialized impact testing machines to simulate hitting potholes and curbs, ensuring the hub flange and internal bearing can withstand sudden, extreme forces without fracturing.

Q3: Is the ABS signal tested at different temperatures?

A: Absolutely. We verify the encoder ring's signal strength and accuracy across a wide temperature range to ensure the ABS system functions flawlessly in both freezing and scorching conditions.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
