wheel hub bearing unit forDFM-E240310J-B0100\E240310JB0100\4581800\DAC40740042ABS\SL930005\AEW-240310J-B0100

Fit Vehicles /Application :DFM-AEOLUS S30 / H30 / H30 Cross

AOZ NO:LD716

OE Numbers:E240310J-B0100, E240310JB0100, 4581800, DAC40740042ABS

Cross Reference Numbers:DAC40740042ABS, SL930005, AEW-240310J-B0100, RM930280

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application :DFM-AEOLUS S30 / H30 / H30 Cross

AOZ NO:LD716

OE Numbers:E240310J-B0100, E240310JB0100, 4581800, DAC40740042ABS

Cross Reference Numbers:DAC40740042ABS, SL930005, AEW-240310J-B0100, RM930280

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
DFM--E240310J-B0100	A.B.S.: 201721
E240310JB0100	SKF: VKBA7582
4581800	GSP: 9219520K
DAC40740042ABS	SNR: R17970
SL930005	FAG: 713611793
AEW-240310J-B0100	FEBI BILSTEIN: 173295

Fit Vehicles
AEOLUS
S30	20092016
H30	20102016
H30 Cross	20112016

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: Are your hub units suitable for Electric Vehicles (EVs)?

A: Yes. We offer specialized hub units engineered to withstand the higher instantaneous torque and heavier vehicle weight typical of electric cars.

Q2: Do EVs cause faster wear on wheel bearings?

A: EVs are heavier and use regenerative braking, which puts different stress loads on the hub. Our EV-specific units feature reinforced dynamic load capacities to handle this.

Q3: Are there any special installation notes for EV hubs?

A: Always follow the specific torque specifications for EVs. Additionally, ensure the ABS sensor connector is securely plugged in, as EVs rely heavily on precise wheel speed data.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
