wheel hub bearing unit forSAIC-6613303325\C00026944\C00033171\C00050631\SYB-197T\6613303326\MAX-00126\DAC45840042

Fit Vehicles /Application :China MAXUS G10

AOZ NO:LD638

OE Numbers:6613303325, C00026944, C00033171, C00050631

Cross Reference NumbersVKBA7120, R17610, 9221022K, 713611420

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

EMAIL

Fit Vehicles /Application :China MAXUS G10

AOZ NOLD638

OE Numbers:6613303325, C00026944, C00033171, C00050631

Cross Reference NumbersVKBA7120, R17610, 9221022K, 713611420

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers







OEM-NUMBER

Cross Reference code

SAIC----6613303325

SKF:VKBA7120

C00026944

SNR:R17610

C00033171

GSP:9221022K

C00050631

NTN:WBK17052

SYB-197T

FAG:713611420

6613303326

FEBI BILSTEIN:173505

MAX-00126

MOOG:SA-WB-12220

DAC45840042

OPTIMAL:964610







Fit Vehicles


MAXUS


G10

2014–2025

EG10

2016–2024

G20

2019–2025

GENERAL PRODUCT DATA

Brand or Logo

AOZ or customer brand

Place of Origin

China, Zhejiang



Product Name

AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit

Packing

White Box / Colour Box / Customized

Certification

ISO/TS16949 - 2016

Sample

Available

Delivery

Sea / Air / Land / Express

Supply Ability

10000 Piece / Per Month

Port

Shanghai, Ningbo, Yiwu, Guangzhou

ABS Sensor

Yes





ACCURACY SPECIFICATIONS

Bearing materials

GCr15 = SAE52100

Flange materials

55# Steel (High quality)

Ball / roller materials

GCr15 = SAE52100

Cage materials

Top Grade PA66 + GF25

Seal materials

Stainless steel + NBR

Wheel stud grade

10.9

Bearing rings hardness control

60-66 HRC

Ball / roller hardness control

61-66 HRC

Inner and outer ring race max roughness control



≤0.20μm

Inner and outer ring race max roundness control



≤3μm

Product inspection

100%

Quality Guarantee

2 years or 60,000 Kilometers














FAQs

Q1: What is the correct installation torque for the wheel hub?

A: It is critical to use a calibrated torque wrench to tighten the axle nut or bolts to the vehicle manufacturer's exact specifications. Over-tightening can damage the bearing, while under-tightening can lead to wheel wobble.

Q2: Can I hammer the hub unit into place during installation?

A: Absolutely not. Never strike the hub unit directly with a hammer or mallet, as this can cause internal micro-fractures in the bearing raceways. Always use a proper hydraulic press or specialized installation tool.

Q3: Do I need to grease the hub unit before installing it?

A: No. Modern wheel hub units are pre-greased and sealed for life. Attempting to disassemble the unit or add extra grease will destroy the internal seals and cause premature failure.

 "Quality First, Customers First",  "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
