wheel hub bearing unit for SAIC-10094077\10094078\DWH0921\SL930812\10072410\10072411\10061320\DAC40750037

Fit Vehicles /Application :ROEWE RX5, W/O ABS

AOZ NO：LD636

OE Numbers:10094077, 10094078, DWH0921, SL930812

Cross Reference Numbers:VKBA7015, R17520, 9220015K, 713611350

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application :ROEWE RX5, W/O ABS

AOZ NO：LD636

OE Numbers:10094077, 10094078, DWH0921, SL930812

Cross Reference Numbers:VKBA7015, R17520, 9220015K, 713611350

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
SAIC----10094077	SKF:VKBA7015
10094078	SNR:R17520
DWH0921	GSP:9220015K
SL930812	NTN:WBK17045
10072410	FAG:713611350
10072411	FEBI BILSTEIN:173102
10061320	MOOG:SA-WB-12150
DAC40750037	OPTIMAL:964520

Fit Vehicles
ROEWE RX5 (W/O ABS )	2016–2023
MG GS	2015–2019
ROEWE RX5	2020–2024

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: Does this hub assembly include an ABS sensor?

A: Yes, as shown in the image, this unit comes with an integrated ABS sensor and cable. It is plug-and-play, requiring no additional modifications during installation.

Q2: Is the ABS tone ring (encoder) built into the bearing?

A: Correct. The magnetic encoder ring is integrated directly into the bearing seal. This design provides more accurate speed signal transmission compared to traditional external toothed rings.

Q3: How do I test if the ABS function is working after installation?

A: After installation, you can use an OBDII scanner to check for any ABS fault codes. A simple road test at low speed should also clear any initial system warnings if installed correctly.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
