SAIC-K4143109101\K4143109102\10010234\10010235\10020456\10020457\10030123\10030124 wheel hub bearing

Fit Vehicles /Application :Roewe W5 4WD

AOZ NO：LD635

OE Numbers:K4143109101, K4143109102, 10010234, 10010235

Cross Reference Numbers:VKBA6891, R17390, 9217011K, 713611120

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application :Roewe W5 4WD

AOZ NO：LD635

OE Numbers:K4143109101, K4143109102, 10010234, 10010235

Cross Reference Numbers:VKBA6891, R17390, 9217011K, 713611120

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
SAIC----K4143109101	SKF:VKBA6891
K4143109102	SNR:R17390
10010234	GSP:9217011K
10010235	NTN:WBK17021
10020456	FAG:713611120
10020457	FEBI BILSTEIN:172402
10030123	MOOG:SA-WB-11990
10030124	OPTIMAL:964010

Fit Vehicles
ROEWE
W5 4WD	2011–2017
SSANGYON
ACTYON 4WD	2012–2018
KORANDO C 4WD	2011–2019

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: How can I ensure the wheel hub unit fits my vehicle model?

A: We have a comprehensive database matching OE numbers and vehicle models. Please provide your VIN (Vehicle Identification Number) or the original part number, and we will confirm the exact fitment for you.

Q2: What is the material composition of the flange and housing?

A: The flange is typically made of high-strength forged steel to withstand heavy loads, while the housing is constructed from precision-machined cast iron or aluminum alloy to ensure structural integrity and heat dissipation.

Q3: Are these units pre-greased and sealed?

A: Yes, all our wheel hub units come pre-filled with high-performance, long-life grease and are equipped with multi-lip seals to prevent contamination from water, dust, and debris.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
