wheel hub bearing unit forSGMW-23548543\DACF43800041\SL930952\BAOJUN510-FRONT-NOABS\DWH01286\SGMW-23548543\DACF43800041\WF4380

Fit Vehicles /Application : SGMW---BAOJUN 510 Front Wheel Without ABS

AOZ NO:LD696

OE Numbers:23548543, DACF43800041, SL930952

Cross Reference Numbers:VKBA7140, R17616, 9219166K, 713611439

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application : SGMW---BAOJUN 510 Front Wheel Without ABS

AOZ NO:LD696

OE Numbers:23548543, DACF43800041, SL930952

Cross Reference Numbers:VKBA7140, R17616, 9219166K, 713611439

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
SGMW---23548543	SKF:VKBA7140
DACF43800041	SNR:R17616
SL930952	GSP:9219166K
BAOJUN510-FRONT-NOABS	NTN:WBK17080
DWH01286	FAG:713611439
SGMW-23548543	FEBI BILSTEIN:172941
DACF43800041	MOOG:SA-WB-12246
WF4380	OPTIMAL:964446

Fit Vehicles
BAOJUN
510 Front Without ABS	2017–2024

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: What information do you need to find the right hub for me?

A: The most accurate way is to provide the VIN (Vehicle Identification Number) or the OE part number from your current hub. Year, make, and model are also helpful.

Q2: Are your hubs compatible with my existing ABS sensors?

A: If you are buying a hub without an integrated sensor, it will work with your original ABS sensor. If buying a hub with an integrated sensor, it replaces the need for a separate sensor entirely.

Q3: Do you offer technical support if I am unsure about fitment?

A: Yes, our engineering team is available to help. You can send us photos of your current hub, and we will cross-reference it to guarantee the correct match.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
