wheel hub bearing unit forSGMW-24535046\DACF42780041ABS\SL930926\BAOJUN630-REAR-ABS\DWH01268\SGMW-24535046\DACF42780041ABS\WF4278-ABS

Fit Vehicles /Application : SGMW---BAOJUN 630, BAOJUN 610 Rear Wheel With ABS

AOZ NO:LD693

OE Numbers:24535046, DACF42780041ABS, SL930926

Cross Reference Numbers:VKBA7118, R17598, 9219148K, 713611421

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

EMAIL

Fit Vehicles /Application : SGMW---BAOJUN 630, BAOJUN 610 Rear Wheel With ABS

AOZ NOLD693

OE Numbers:24535046, DACF42780041ABS, SL930926

Cross Reference Numbers:VKBA7118, R17598, 9219148K, 713611421

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers




OEM-NUMBER

Cross Reference code

SGMW---24535046

SKF:VKBA7118

DACF42780041ABS

SNR:R17598

SL930926

GSP:9219148K

BAOJUN630-REAR-ABS

NTN:WBK17066

DWH01268

FAG:713611421

SGMW-24535046

FEBI BILSTEIN:172923

DACF42780041ABS

MOOG:SA-WB-12228

WF4278-ABS

OPTIMAL:964428





Fit Vehicles


BAOJUN


630 Rear With ABS

2011–2018

610 Rear With ABS

2014–2017


GENERAL PRODUCT DATA

Brand or Logo

AOZ or customer brand

Place of Origin

China, Zhejiang



Product Name

AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit

Packing

White Box / Colour Box / Customized

Certification

ISO/TS16949 - 2016

Sample

Available

Delivery

Sea / Air / Land / Express

Supply Ability

10000 Piece / Per Month

Port

Shanghai, Ningbo, Yiwu, Guangzhou

ABS Sensor

Yes





ACCURACY SPECIFICATIONS

Bearing materials

GCr15 = SAE52100

Flange materials

55# Steel (High quality)

Ball / roller materials

GCr15 = SAE52100

Cage materials

Top Grade PA66 + GF25

Seal materials

Stainless steel + NBR

Wheel stud grade

10.9

Bearing rings hardness control

60-66 HRC

Ball / roller hardness control

61-66 HRC

Inner and outer ring race max roughness control



≤0.20μm

Inner and outer ring race max roundness control



≤3μm

Product inspection

100%

Quality Guarantee

2 years or 60,000 Kilometers















FAQs

Q1: Why are maintenance-free hub units more cost-effective in the long run?

A: Although the initial purchase price might be slightly higher, they eliminate the recurring labor costs of cleaning, repacking, and adjusting bearings. They also significantly reduce vehicle downtime.



Q2: How does your hub unit improve fuel efficiency?

A: Our units are designed with optimized internal geometry and premium low-friction grease, which reduces the rotational friction torque and rolling resistance, directly saving fuel or extending EV range.



Q3: What happens if I try to disassemble a sealed hub unit?

A: Disassembling a sealed unit will destroy the factory-precision seals and internal clearances. This will immediately void the warranty and lead to rapid, premature failure.



"Quality First, Customers First",  "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
