P11-3001015 Wheel Hub Bearing Unit For CHERY

P11-3001015 Wheel Hub Bearing Unit For CHERY

Fit Vehicles /Application CHERY V5/X5 P11 2009-

AOZ NO：LD614

OENumbers:P11-3001015

Cross Reference Numbers:PRORUN:P11-3001015

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application CHERY V5/X5 P11 2009-

AOZ NO：LD614

OENumbers:P11-3001015

Cross Reference Numbers:PRORUN:P11-3001015

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER:	Cross Reference code
CHERY-------P11-3001015	PRORUN:P11-3001015

Fit Vehicles
CHERY
V5	2009-2013
X5(P11)	2009-2014

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: What is your terms of payments?
A: Full payment for less than $3000 orders. 30% T/T in advance, 70% against B/L for over $3000 orders.

Q2: What is the MOQ (Minimum Order Quantity)?
A: Our MOQ is 10 pieces per model. For trial orders, we accept smaller quantities to help you test the market.

Q3: What is the lead time for production and delivery?
A: For stock items, delivery is 3-7 working days after payment. For custom orders, lead time is approximately 15-30 working days depending on quantity.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
