Fit Vehicles /Application :Chrysler Dodge Plymouth-Chrysler 300,Dodge Challenger, Charger
AOZ NO:LD065
OE Numbers:512555
Cross Reference Numbers:
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
Fit Vehicles /Application :Chrysler Dodge Plymouth-Chrysler 300,Dodge Challenger, Charger
AOZ NO:LD065
OE Numbers:512555
Cross Reference Numbers:
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
OEM-NUMBER | Cross Reference code |
Chrysler Dodge Plymouth-512555 | |
Fit Vehicles | |
Chrysler | |
300 | 2015-2023 |
Dodge | |
Challenger | 2015-2023 |
Charger | 2015-2023 |
GENERAL PRODUCT DATA | |
Brand or Logo | AOZ or customer brand |
Place of Origin | China, Zhejiang |
Product Name | AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit |
Packing | White Box / Colour Box / Customized |
Certification | ISO/TS16949 - 2016 |
Sample | Available |
Delivery | Sea / Air / Land / Express |
Supply Ability | 10000 Piece / Per Month |
Port | Shanghai, Ningbo, Yiwu, Guangzhou |
ABS Sensor | Yes |
ACCURACY SPECIFICATIONS | |
Bearing materials | GCr15 = SAE52100 |
Flange materials | 55# Steel (High quality) |
Ball / roller materials | GCr15 = SAE52100 |
Cage materials | Top Grade PA66 + GF25 |
Seal materials | Stainless steel + NBR |
Wheel stud grade | 10.9 |
Bearing rings hardness control | 60-66 HRC |
Ball / roller hardness control | 61-66 HRC |
Inner and outer ring race max roughness control |
≤0.20μm |
Inner and outer ring race max roundness control |
≤3μm |
Product inspection | 100% |
Quality Guarantee | 2 years or 60,000 Kilometers |







FAQs
Q1: Can a bad hub bearing cause my car to fail an emissions test?
A: Yes, indirectly. If the ABS sensor failure triggers the Check Engine light, many emissions testing stations will automatically fail the vehicle, since an illuminated MIL means the onboard diagnostics are not ready for testing.
Q2: Why does the hub flange have a thin paper or rubber gasket on the mounting face?
A: This gasket prevents direct metal-to-metal contact between the hub and the knuckle, which helps prevent galvanic corrosion — especially on vehicles with aluminum knuckles and steel hubs. Do not remove it during installation.
Q3: Can I replace a hub assembly in cold weather without issues?
A: You can, but be aware that cold metal contracts, making bolts and studs harder to remove. It also makes rubber seals and wiring insulation more brittle. If possible, warm the vehicle in a garage before starting the job to avoid snapping bolts or cracking connectors.
