Wheel-hub-bearing-unit-for-FAW-5GA0-33-04X\5GA03304X

Fit Vehicles /Application :FAW-Besturn B90

AOZ NO:LD761

OE Numbers:5GA0-33-04X,5GA03304X

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

EMAIL

Fit Vehicles /Application :FAW-Besturn B90

AOZ NO:LD761

OE Numbers:5GA0-33-04X,5GA03304X

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER

Cross Reference code

FAW-5GA0-33-04X


5GA03304X




Fit Vehicles


Besturn


B90

2012-2016

GENERAL PRODUCT DATA

Brand or Logo

AOZ or customer brand

Place of Origin

China, Zhejiang



Product Name

AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit

Packing

White Box / Colour Box / Customized

Certification

ISO/TS16949 - 2016

Sample

Available

Delivery

Sea / Air / Land / Express

Supply Ability

10000 Piece / Per Month

Port

Shanghai, Ningbo, Yiwu, Guangzhou

ABS Sensor

Yes





ACCURACY SPECIFICATIONS

Bearing materials

GCr15 = SAE52100

Flange materials

55# Steel (High quality)

Ball / roller materials

GCr15 = SAE52100

Cage materials

Top Grade PA66 + GF25

Seal materials

Stainless steel + NBR

Wheel stud grade

10.9

Bearing rings hardness control

60-66 HRC

Ball / roller hardness control

61-66 HRC

Inner and outer ring race max roughness control



≤0.20μm

Inner and outer ring race max roundness control



≤3μm

Product inspection

100%

Quality Guarantee

2 years or 60,000 Kilometers


















FAQs

Q1: Can I use anti-seize compound on the hub mounting surface?

A: Yes, but use it sparingly. A very thin layer of anti-seize on the clean knuckle surface prevents future rust buildup, but too much can alter the seating position and cause runout.



Q2: How do I know if my hub has an integrated ABS sensor?

A: Check the part description or look at the hub. Integrated hubs have a built-in magnetic encoder ring on the inner seal and often include a wiring harness connector built directly into the housing.



Q3: What happens if I over-torque the axle nut?

A: Over-torquing crushes the internal bearing rollers and races, eliminating the necessary clearance. This creates extreme friction, generates excessive heat, and will cause the new hub to fail very quickly.

"Quality First, Customers First",  "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
