Wheel-hub-bearing-unit-for-GM-USA-512239

Fit Vehicles/Application:GM-USA-Saturn: L Sedan, L300, LW Wagon

AOZ NO:LD112

OE Numbers:512239

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

EMAIL

Fit Vehicles/Application:GM-USA-Saturn: L Sedan, L300, LW Wagon

AOZ NO:LD112

OE Numbers:512239

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER

Cross Reference code

GM-USA-512239





Fit Vehicles


Saturn


 L Sedan

1999-2004

L300

2000-2005

LW Wagon

2000-2005


GENERAL PRODUCT DATA

Brand or Logo

AOZ or customer brand

Place of Origin

China, Zhejiang



Product Name

AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit

Packing

White Box / Colour Box / Customized

Certification

ISO/TS16949 - 2016

Sample

Available

Delivery

Sea / Air / Land / Express

Supply Ability

10000 Piece / Per Month

Port

Shanghai, Ningbo, Yiwu, Guangzhou

ABS Sensor

Yes



ACCURACY SPECIFICATIONS

Bearing materials

GCr15 = SAE52100

Flange materials

55# Steel (High quality)

Ball / roller materials

GCr15 = SAE52100

Cage materials

Top Grade PA66 + GF25

Seal materials

Stainless steel + NBR

Wheel stud grade

10.9

Bearing rings hardness control

60-66 HRC

Ball / roller hardness control

61-66 HRC

Inner and outer ring race max roughness control



≤0.20μm

Inner and outer ring race max roundness control



≤3μm

Product inspection

100%

Quality Guarantee

2 years or 60,000 Kilometers
















FAQs

Q1: Why does my hub bearing make a droning noise that sounds like it is coming from the opposite side of the vehicle?

A: Bearing noise can resonate through the chassis and subframe, making it difficult to pinpoint the source. The sound may appear to come from the opposite side due to how vibrations travel through the vehicle structure.


Q2: Why does my new hub have a small metal clip holding the ABS wire to the housing?

A: This clip secures the wire in the correct position during shipping and provides a reference point for proper routing during installation. It can be removed once the wire is routed along the factory path.


Q3: Can a hub bearing failure cause my vehicle to make a noise that sounds like a tire with a nail in it?

A: Yes. A damaged bearing with localized pitting on the raceway can produce a rhythmic clicking or tapping sound that mimics a nail in a tire. Rule out tire issues first, then inspect the bearing.

Quality First, Customers First",  "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
