Wheel-hub-bearing-unit-for-GM-USA-512243

Wheel-hub-bearing-unit-for-GM-USA-512243

Fit Vehicles/Application:GM-USA-Cadillac CTS,SrX,STS

AOZ NO:L-075

OE Numbers:512243

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles/Application:GM-USA-Cadillac CTS,SrX,STS

AOZ NO:L-075

OE Numbers:512243

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
GM-USA-512243

Fit Vehicles
Cadillac
CTS	2002-2019
SrX	2004-2016
STS	2005-2011

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: What causes a hub bearing to make a whining noise that only appears when coasting?

A: Coasting removes drive torque from the bearing, changing which internal surfaces carry the load. If damage is on the coast-side of the raceway, the whine may only appear when the load shifts during deceleration.

Q2: Why does my new hub have a small raised bump on the ABS sensor housing?

A: This bump is a manufacturing reference point used during assembly to verify correct sensor positioning. It has no effect on installation or performance.

Q3: Can a bad hub bearing cause my vehicle to make a vibration that feels like the wheels are out of balance?

A: Yes. A worn bearing creates uneven rotation that mimics the sensation of an out-of-balance wheel. If rebalancing the tires does not resolve the vibration, inspect the hub bearings.

“Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
