Wheel-hub-bearing-unit-for-GM-USA-513200

Fit Vehicles/Application:GM-USA-CHEVROLET BLAZER ,GMC JIMMY

AOZ NO:LD133

OE Numbers:513200

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

EMAIL

Fit Vehicles/Application:GM-USA-CHEVROLET BLAZER ,GMC JIMMY

AOZ NO:LD133

OE Numbers:513200

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER

Cross Reference code

GM-USA-513200





Fit Vehicles


CHEVROLET


BLAZER

1998-2005

GMC


JIMMY

1998-2001

GENERAL PRODUCT DATA

Brand or Logo

AOZ or customer brand

Place of Origin

China, Zhejiang



Product Name

AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit

Packing

White Box / Colour Box / Customized

Certification

ISO/TS16949 - 2016

Sample

Available

Delivery

Sea / Air / Land / Express

Supply Ability

10000 Piece / Per Month

Port

Shanghai, Ningbo, Yiwu, Guangzhou

ABS Sensor

Yes



ACCURACY SPECIFICATIONS

Bearing materials

GCr15 = SAE52100

Flange materials

55# Steel (High quality)

Ball / roller materials

GCr15 = SAE52100

Cage materials

Top Grade PA66 + GF25

Seal materials

Stainless steel + NBR

Wheel stud grade

10.9

Bearing rings hardness control

60-66 HRC

Ball / roller hardness control

61-66 HRC

Inner and outer ring race max roughness control



≤0.20μm

Inner and outer ring race max roundness control



≤3μm

Product inspection

100%

Quality Guarantee

2 years or 60,000 Kilometers














FAQs

Q1: Why does my hub bearing make a noise that only appears when the vehicle is cold?
A: Cold temperatures cause the grease inside the bearing to thicken, increasing internal friction. If the bearing has minor wear, the thicker grease can amplify noise during the first few minutes of driving until the bearing warms up and the grease thins out.


Q2: Why does my new hub have a small engraved arrow on the ABS sensor body?
A: Some sensor assemblies are directional and must be installed in a specific orientation. The arrow indicates the correct installation direction relative to the encoder ring — always follow the manufacturer's instructions.


Q3: Can a hub bearing failure cause my vehicle to make a noise that sounds like a failing power steering pump?
A: Yes. Both can produce a whining or groaning sound that changes with steering input. To differentiate, check whether the noise changes with vehicle speed (hub bearing) or steering wheel position (power steering pump).

“Quality First, Customers First",  "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
