Wheel-hub-bearing-unit-for-GM-USA-513204

Fit Vehicles/Application:GM-USA-CHEVROLET COBALT ,PONTIAC G5 ,PURSUIT ,SATURN ION

AOZ NO:LD134

OE Numbers:513204

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

EMAIL

Fit Vehicles/Application:GM-USA-CHEVROLET COBALT ,PONTIAC G5 ,PURSUIT ,SATURN ION

AOZ NO:LD134

OE Numbers:513204

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER

Cross Reference code

GM-USA-513204





Fit Vehicles


CHEVROLET


COBALT

2005-2010

PONTIAC


G5

2007-2010

PURSUIT

2005-2006

SATURN


ION

2003-2007

GENERAL PRODUCT DATA

Brand or Logo

AOZ or customer brand

Place of Origin

China, Zhejiang



Product Name

AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit

Packing

White Box / Colour Box / Customized

Certification

ISO/TS16949 - 2016

Sample

Available

Delivery

Sea / Air / Land / Express

Supply Ability

10000 Piece / Per Month

Port

Shanghai, Ningbo, Yiwu, Guangzhou

ABS Sensor

Yes



ACCURACY SPECIFICATIONS

Bearing materials

GCr15 = SAE52100

Flange materials

55# Steel (High quality)

Ball / roller materials

GCr15 = SAE52100

Cage materials

Top Grade PA66 + GF25

Seal materials

Stainless steel + NBR

Wheel stud grade

10.9

Bearing rings hardness control

60-66 HRC

Ball / roller hardness control

61-66 HRC

Inner and outer ring race max roughness control



≤0.20μm

Inner and outer ring race max roundness control



≤3μm

Product inspection

100%

Quality Guarantee

2 years or 60,000 Kilometers















FAQs

Q1: Why does my hub bearing make a noise that only appears when the vehicle is turning right?

A: Turning right shifts the vehicle's weight onto the left-side bearing, increasing its load. If the left bearing has internal damage, the added load amplifies the noise, while the unloaded right bearing may become quieter.


Q2: Why does my new hub have a small plastic insert in the ABS connector?

A: The insert protects the connector pins from dust, moisture, and physical damage during shipping and storage. Remove it before plugging the connector into the vehicle's wiring harness.


Q3: Can a hub bearing failure cause my vehicle to make a vibration that is felt in the floorboard on the passenger side?

A: Yes. A failing right-side rear bearing can transmit vibration through the suspension and chassis directly into the passenger side floor area. The location of the vibration often corresponds to the side of the failing bearing.

“Quality First, Customers First",  "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
