Wheel-hub-bearing-unit-for-HAIMA-SA00-330-60M1\SA0033060M1

Fit Vehicles /Application :HAIMA-7 Front

AOZ NO:LD796

OE Numbers:SA00-330-60M1,SA0033060M1

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application :HAIMA-7 Front

AOZ NO:LD796

OE Numbers:SA00-330-60M1,SA0033060M1

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
HAIMA-SA00-330-60M1
SA0033060M1

Fit Vehicles
HAIMA
7 Front	2010-2015

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: What is the difference between a standard hub and an ABS-integrated hub?
A: Standard hubs only support the wheel. ABS-integrated hubs have a magnetic encoder ring. Using the wrong type will trigger an ABS warning light.

Q2: My vehicle has an aluminum steering knuckle. Are there special installation rules?
A: Yes. Aluminum is soft and damages easily. Always use a press tool, follow exact torque specs, and never reuse the original bolts.

Q3: What are torque-to-yield bolts?
A: These bolts stretch during installation for maximum clamping force. They are single-use only and must be replaced with new ones.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
