Fit Vehicles /Application :SorthEast-V5, V6
AOZ NO:LD756
OE Numbers:DV513192S
Cross Reference Numbers:
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
Fit Vehicles /Application :SorthEast-V5, V6
AOZ NO:LD756
OE Numbers:DV513192S
Cross Reference Numbers:
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
OEM-NUMBER | Cross Reference code |
SorthEast-DV513192S | |
Fit Vehicles | |
SorthEast | |
V5 | 2012-2015 |
V6 | 2013-2015 |
GENERAL PRODUCT DATA | |
Brand or Logo | AOZ or customer brand |
Place of Origin | China, Zhejiang |
Product Name | AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit |
Packing | White Box / Colour Box / Customized |
Certification | ISO/TS16949 - 2016 |
Sample | Available |
Delivery | Sea / Air / Land / Express |
Supply Ability | 10000 Piece / Per Month |
Port | Shanghai, Ningbo, Yiwu, Guangzhou |
ABS Sensor | Yes |
ACCURACY SPECIFICATIONS | |
Bearing materials | GCr15 = SAE52100 |
Flange materials | 55# Steel (High quality) |
Ball / roller materials | GCr15 = SAE52100 |
Cage materials | Top Grade PA66 + GF25 |
Seal materials | Stainless steel + NBR |
Wheel stud grade | 10.9 |
Bearing rings hardness control | 60-66 HRC |
Ball / roller hardness control | 61-66 HRC |
Inner and outer ring race max roughness control |
≤0.20μm |
Inner and outer ring race max roundness control |
≤3μm |
Product inspection | 100% |
Quality Guarantee | 2 years or 60,000 Kilometers |
FAQs
Q1: Can I drive with a missing wheel stud?
A: No. A missing stud puts extra stress on the remaining studs and the hub, which can cause them to fail. It also prevents the wheel from seating properly, leading to dangerous vibrations.
Q2: What causes a hub to make a clicking noise?
A: A clicking noise is usually not from the hub itself. It is more likely caused by a worn CV joint, a loose brake caliper, or a damaged wheel bearing that has lost its preload.
Q3: Do I need to reset the TPMS after replacing a hub?
A: Only if your vehicle has direct TPMS sensors mounted on the hub. If the sensor was removed or replaced, you will need to relearn or reset the system using a scan tool.
