Wheel-hub-bearing-unit-for-SorthEast-SW803146

Fit Vehicles /Application :SorthEast-Lioncel, V3
AOZ NO:LD755
OE Numbers:SW803146
Cross Reference Numbers:
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers

EMAIL

Fit Vehicles /Application :SorthEast-Lioncel, V3

AOZ NO:LD755

OE Numbers:SW803146

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER

Cross Reference code

SorthEast-SW803146






Fit Vehicles


SorthEast


Lioncel

1979-1991

V3

2015-2020

GENERAL PRODUCT DATA

Brand or Logo

AOZ or customer brand

Place of Origin

China, Zhejiang



Product Name

AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit

Packing

White Box / Colour Box / Customized

Certification

ISO/TS16949 - 2016

Sample

Available

Delivery

Sea / Air / Land / Express

Supply Ability

10000 Piece / Per Month

Port

Shanghai, Ningbo, Yiwu, Guangzhou

ABS Sensor

Yes





ACCURACY SPECIFICATIONS

Bearing materials

GCr15 = SAE52100

Flange materials

55# Steel (High quality)

Ball / roller materials

GCr15 = SAE52100

Cage materials

Top Grade PA66 + GF25

Seal materials

Stainless steel + NBR

Wheel stud grade

10.9

Bearing rings hardness control

60-66 HRC

Ball / roller hardness control

61-66 HRC

Inner and outer ring race max roughness control



≤0.20μm

Inner and outer ring race max roundness control



≤3μm

Product inspection

100%

Quality Guarantee

2 years or 60,000 Kilometers














FAQs

Q1: Can I use an old hub as a spare part?

A: No. Wheel hubs are sealed, precision components. Once removed, they cannot be safely reused or stored as spares due to potential internal damage and contamination.



Q2: Why does my car vibrate when braking after a hub replacement?

A: This usually means the brake rotor was not properly cleaned or was warped by the previous failing hub. The rotor needs to be resurfaced or replaced to ensure a smooth braking surface.



Q3: How do I know if my hub has a tone ring for ABS?

A: Most modern hubs have an integrated magnetic encoder ring built into the seal. Older models may have a separate toothed tone ring pressed onto the axle shaft. Check your vehicle's service manual to confirm.

"Quality First, Customers First",  "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
