wheel-hub-bearing-unit-for-Chery-T21-3301210\T213301210

Fit Vehicles /Application Chery Tiggo 5 / B12 / T21

AOZ NO：LD610

OENumbers:T21-3301210,T213301210
Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application Chery Tiggo 5 / B12 / T21

AOZ NO：LD610

OENumbers:T21-3301210,T213301210

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
CHERY-T21-3301210
T213301210

Fit Vehicles
CHERY
Tiggo 5	2013-2017

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: Can you provide the product drawing or technical data sheet?

A: Yes, we can provide 2D drawings, 3D models, and detailed technical specifications upon request for engineering confirmation.

Q2: What certificates do you hold besides IATF 16949?

A: We are certified with IATF 16949:2016. We can also provide material test reports, dimension inspection reports, and hardness test reports for each batch.

Q3: How do you handle complaints or quality issues?

A: We take all complaints seriously. Our after-sales team will respond within 24 hours, analyze the root cause, and provide solutions including replacement, refund, or credit note for future orders.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
