Fit Vehicles /Application :CHANGAN Zhixiang / Eado XT (Rear Wheel With ABS)
AOZ NO：LD651
OE Numbers:CV8, 15007032, 15007033, DAC43780041ABS, SL930772
Cross Reference Numbers:VKBA6980, R17470, 9219012K, 713611285
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
Fit Vehicles /Application :CHANGAN Zhixiang / Eado XT (Rear Wheel With ABS)
AOZ NO：LD651
OE Numbers:CV8, 15007032, 15007033, DAC43780041ABS, SL930772
Cross Reference Numbers:VKBA6980, R17470, 9219012K, 713611285
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
OEM-NUMBER | Cross Reference code |
CHANGAN----CV8 | SKF:VKBA6980 |
15007032 | SNR:R17470 |
15007033 | GSP:9219012K |
DAC43780041ABS | NTN:WBK17039 |
ZX-3203010 | FAG:713611285 |
SL930772 | FEBI BILSTEIN:172795 |
DAC43780041 | MOOG:SA-WB-12100 |
W4378 | OPTIMAL:964300 |
Fit Vehicles | |
CHANGAN | |
Zhixiang | 2008–2013 |
Eado XT | 2013–2020 |
GENERAL PRODUCT DATA | |
Brand or Logo | AOZ or customer brand |
Place of Origin | China, Zhejiang |
Product Name | AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit |
Packing | White Box / Colour Box / Customized |
Certification | ISO/TS16949 - 2016 |
Sample | Available |
Delivery | Sea / Air / Land / Express |
Supply Ability | 10000 Piece / Per Month |
Port | Shanghai, Ningbo, Yiwu, Guangzhou |
ABS Sensor | Yes |
ACCURACY SPECIFICATIONS | |
Bearing materials | GCr15 = SAE52100 |
Flange materials | 55# Steel (High quality) |
Ball / roller materials | GCr15 = SAE52100 |
Cage materials | Top Grade PA66 + GF25 |
Seal materials | Stainless steel + NBR |
Wheel stud grade | 10.9 |
Bearing rings hardness control | 60-66 HRC |
Ball / roller hardness control | 61-66 HRC |
Inner and outer ring race max roughness control |
≤0.20μm |
Inner and outer ring race max roundness control |
≤3μm |
Product inspection | 100% |
Quality Guarantee | 2 years or 60,000 Kilometers |
FAQs
Q1: How do your hub units handle water and mud?
A: They feature multi-lip seals designed to block water, mud, and road debris, keeping the internal grease clean and preventing premature wear.
Q2: Are they resistant to road salt corrosion?
A: Yes. The flanges and housings are coated with anti-corrosion treatments to withstand harsh winter conditions and salty roads.
Q3: Can they operate in high-temperature braking zones?
A: Absolutely. We use high-temperature synthetic grease that maintains its viscosity even when brake discs generate extreme heat.
