wheel hub bearing unit forGREAT WALL-3001101-K01\3103012-K01\3001101K01\3103012K01\HOVER-H3-H5-SAFEF1-FRONT\GW-3001101-K01\DAC50890042\W5089

Fit Vehicles /Application :GREAT WALL HOVER H3, HOVER H5, GREAT WALL SAFE F1 Front Wheel Hub Bearing

AOZ NO：LD686

OE Numbers:3001101K01, 3103012K01, DAC50890042, SL930416

Cross Reference Numbers: VKBA6836, R17354, 9216033K, 713611084

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application :GREAT WALL HOVER H3, HOVER H5, GREAT WALL SAFE F1 Front Wheel Hub Bearing

AOZ NO：LD686

OE Numbers:3001101K01, 3103012K01, DAC50890042, SL930416

Cross Reference Numbers: VKBA6836, R17354, 9216033K, 713611084

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
GREAT WALL---3001101-K01	SKF:VKBA6836
3103012-K01	SNR:R17354
3001101K01	GSP:9216033K
3103012K01	NTN:WBK17018
HOVER-H3-H5-SAFEF1-FRONT	FAG:713611084
GW-3001101-K01	FEBI BILSTEIN:172228
DAC50890042	MOOG:SA-WB-11936
W5089	OPTIMAL:963944

Fit Vehicles
GREAT WALL
HOVER H3 Front	2005–2012
HOVER H5 Front	2010–2017
SAFE F1 Front	2002–2008

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: What makes your bearing steel superior?

A: We use ultra-high purity bearing steel (e.g., GCr15) with extremely low oxygen content, which maximizes fatigue resistance and prevents premature internal spalling.

Q2: How do you ensure the flange can handle high stress?

A: The flange is forged from high-strength carbon steel and undergoes precise heat treatment, ensuring stress is evenly distributed while keeping the weight low.

Q3: What is the "riveting" process used in your assembly?

A: We use advanced orbital riveting (swaging) technology instead of traditional nuts, creating a permanent lock that improves reliability and reduces overall weight.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
