Fit Vehicles /Application :GREAT WALL HAVAL H1 Rear Wheel With ABS
AOZ NO：LD682
OE Numbers:3104100-M23-B1, 3104100M23B1, DAC2F76R6418, SL930842
Cross Reference Numbers: VKBA7064, R17546, 9219096K, 713611369
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
Fit Vehicles /Application :GREAT WALL HAVAL H1 Rear Wheel With ABS
AOZ NO：LD682
OE Numbers:3104100-M23-B1, 3104100M23B1, DAC2F76R6418, SL930842
Cross Reference Numbers: VKBA7064, R17546, 9219096K, 713611369
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
OEM-NUMBER | Cross Reference code |
GREAT WALL ---3104100-M23-B1 | SKF:VKBA7064 |
3104100M23B1 | SNR:R17546 |
DAC2F76R6418 | GSP:9219096K |
SL930842 | NTN:WBK17052 |
HAVAL-H1-REAR-ABS | FAG:713611369 |
GW-3104100-M23-B1 | FEBI BILSTEIN:172871 |
DAC76640048ABS | MOOG:SA-WB-12176 |
W7664 | OPTIMAL:964376 |
Fit Vehicles | |
GREAT WALL | |
HAVAL H1 Rear ABS | 2014–2021 |
GENERAL PRODUCT DATA | |
Brand or Logo | AOZ or customer brand |
Place of Origin | China, Zhejiang |
Product Name | AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit |
Packing | White Box / Colour Box / Customized |
Certification | ISO/TS16949 - 2016 |
Sample | Available |
Delivery | Sea / Air / Land / Express |
Supply Ability | 10000 Piece / Per Month |
Port | Shanghai, Ningbo, Yiwu, Guangzhou |
ABS Sensor | Yes |
ACCURACY SPECIFICATIONS | |
Bearing materials | GCr15 = SAE52100 |
Flange materials | 55# Steel (High quality) |
Ball / roller materials | GCr15 = SAE52100 |
Cage materials | Top Grade PA66 + GF25 |
Seal materials | Stainless steel + NBR |
Wheel stud grade | 10.9 |
Bearing rings hardness control | 60-66 HRC |
Ball / roller hardness control | 61-66 HRC |
Inner and outer ring race max roughness control |
≤0.20μm |
Inner and outer ring race max roundness control |
≤3μm |
Product inspection | 100% |
Quality Guarantee | 2 years or 60,000 Kilometers |
FAQs
Q1: Are your hubs EV-ready?
A: Yes, they handle the extra weight and regenerative braking.
Q2: What is a Gen 3 hub unit?
A: It’s a lightweight, sealed unit with an integrated ABS sensor.
Q3: Why are newer hubs lighter?
A: Advanced manufacturing reduces weight and improves fuel efficiency.
