Fit Vehicles /Application :GREAT WALL HAVAL H6 4WD Rear Wheel With ABS
AOZ NO：LD680
OE Numbers:3104100XKZ17A, 3104100-XKZ17A, DAC2F82R4528D, SL930794
Cross Reference Numbers: VKBA7038, R17520, 9219070K, 713611343
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
Fit Vehicles /Application :GREAT WALL HAVAL H6 4WD Rear Wheel With ABS
AOZ NO：LD680
OE Numbers:3104100XKZ17A, 3104100-XKZ17A, DAC2F82R4528D, SL930794
Cross Reference Numbers: VKBA7038, R17520, 9219070K, 713611343
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
OEM-NUMBER | Cross Reference code |
GREAT WALL---3104100XKZ17A | SKF:VKBA7038 |
3104100-XKZ17A | SNR:R17520 |
DAC2F82R4528D | GSP:9219070K |
SL930794 | NTN:WBK17050 |
HAVAL-H6-4WD-REAR-ABS | FAG:713611343 |
GW-3104100-XKZ17A | FEBI BILSTEIN:172845 |
DAC42820045ABS-4WD | MOOG:SA-WB-12150 |
W4282-4WD | OPTIMAL:964350 |
Fit Vehicles | |
GREAT WALL | |
HAVAL H6 4WD Rear ABS | 2012–2020 |
GENERAL PRODUCT DATA | |
Brand or Logo | AOZ or customer brand |
Place of Origin | China, Zhejiang |
Product Name | AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit |
Packing | White Box / Colour Box / Customized |
Certification | ISO/TS16949 - 2016 |
Sample | Available |
Delivery | Sea / Air / Land / Express |
Supply Ability | 10000 Piece / Per Month |
Port | Shanghai, Ningbo, Yiwu, Guangzhou |
ABS Sensor | Yes |
ACCURACY SPECIFICATIONS | |
Bearing materials | GCr15 = SAE52100 |
Flange materials | 55# Steel (High quality) |
Ball / roller materials | GCr15 = SAE52100 |
Cage materials | Top Grade PA66 + GF25 |
Seal materials | Stainless steel + NBR |
Wheel stud grade | 10.9 |
Bearing rings hardness control | 60-66 HRC |
Ball / roller hardness control | 61-66 HRC |
Inner and outer ring race max roughness control |
≤0.20μm |
Inner and outer ring race max roundness control |
≤3μm |
Product inspection | 100% |
Quality Guarantee | 2 years or 60,000 Kilometers |
FAQs
Q1: What does a humming noise mean?
A: It usually indicates a worn wheel hub bearing.
Q2: Why does my steering wheel vibrate?
A: It could be a bad hub, unbalanced tires, or warped rotors.
Q3: Does a bad hub trigger the ABS light?
A: Yes, a damaged ABS encoder ring in the hub will trigger it.
"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
