Fit Vehicles /Application :GAC-Trumpchi-GS8 M8
AOZ NO:L-665
OE Numbers:3510003AMV0000(W-D83)
Cross Reference Numbers:
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
Fit Vehicles /Application :GAC-Trumpchi-GS8 M8
AOZ NO:L-665
OE Numbers:3510003AMV0000(W-D83)
Cross Reference Numbers:
Certification: IATF 16949:2016
Quality Guarantee: 2 years or 60000 kilometers
OEM-NUMBER | Cross Reference code |
GAC-Trumpchi-3510003AMV0000(W-D83) | |
Fit Vehicles | |
GAC-Trumpchi | |
GS8 | 2016-Present |
M8 | 2017-Present |
GENERAL PRODUCT DATA | |
Brand or Logo | AOZ or customer brand |
Place of Origin | China, Zhejiang |
Product Name | AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit |
Packing | White Box / Colour Box / Customized |
Certification | ISO/TS16949 - 2016 |
Sample | Available |
Delivery | Sea / Air / Land / Express |
Supply Ability | 10000 Piece / Per Month |
Port | Shanghai, Ningbo, Yiwu, Guangzhou |
ABS Sensor | Yes |
ACCURACY SPECIFICATIONS | |
Bearing materials | GCr15 = SAE52100 |
Flange materials | 55# Steel (High quality) |
Ball / roller materials | GCr15 = SAE52100 |
Cage materials | Top Grade PA66 + GF25 |
Seal materials | Stainless steel + NBR |
Wheel stud grade | 10.9 |
Bearing rings hardness control | 60-66 HRC |
Ball / roller hardness control | 61-66 HRC |
Inner and outer ring race max roughness control |
≤0.20μm |
Inner and outer ring race max roundness control |
≤3μm |
Product inspection | 100% |
Quality Guarantee | 2 years or 60,000 Kilometers |
FAQs
Q1: Can a bad wheel bearing cause my vehicle to fail an emissions test?
A: No. Emissions tests check exhaust gases and fuel system integrity, not wheel bearings. However, a seized bearing could prevent the vehicle from being driven onto the test equipment.
Q2: Why does my steering feel loose or vague after replacing the hub?
A: This could indicate that the hub was not torqued to the correct specification, or that the suspension components were disturbed during the repair. An alignment check is recommended to restore proper steering feel.
Q3: Can I use a heat gun to warm up the knuckle before pressing in a new hub?
A: Yes, but with caution. Gentle warming can expand the aluminum knuckle slightly, making installation easier. However, excessive heat can damage the hub's internal seals and degrade the pre-packed grease.
"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
