Wheel-hub-bearing-unit-for-HAIMA-A3104600

Wheel-hub-bearing-unit-for-HAIMA-A3104600

Fit Vehicles /Application :HAIMA-X50, CELLIYA 530

AOZ NO:LD790

OE Numbers:A3104600

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application :HAIMA-X50, CELLIYA 530

AOZ NO:LD790

OE Numbers:A3104600

Cross Reference Numbers:

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
HAIMA-A3104600

Fit Vehicles
HAIMA
X50	2014-2017
CELLIYA
530	2014-2016

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: Can a bad wheel bearing cause my speedometer to read incorrectly?
A: Yes. The speedometer uses the ABS wheel speed sensor signal. If the hub's magnetic encoder ring is damaged or dirty, the sensor may send intermittent signals, causing the speedometer to fluctuate or stop working.

Q2: Why is there a rubber boot on the ABS connector of some hubs?
A: The boot protects the electrical connection from moisture, road salt, and debris. If this boot is torn or missing during installation, corrosion can develop, leading to intermittent ABS faults.

Q3: Can I install a hub without removing the brake caliper?
A: It depends on the vehicle. On some models, the caliper must be removed to access the hub bolts. On others, the caliper can be hung aside. Always follow the service manual to avoid damaging the brake hose.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
