Wheel-hub-bearing-unit-for-JAC-3103101U7151

Wheel-hub-bearing-unit-for-JAC-3103101U7151

Fit Vehicles /Application :JAC-J7/Benjoy,5 bolts,new model

AOZ NO:LD747

OE Numbers:3103101U7151

Cross Reference Numbers:3103101U7151.1

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

Fit Vehicles /Application :JAC-J7/Benjoy,5 bolts,new model

AOZ NO:LD747

OE Numbers:3103101U7151

Cross Reference Numbers:3103101U7151.1

Certification: IATF 16949:2016

Quality Guarantee: 2 years or 60000 kilometers

OEM-NUMBER	Cross Reference code
JAC-3103101U7151	3103101U7151.1

Fit Vehicles
JAC
J7 Benjoy(new model)	2019-Present

GENERAL PRODUCT DATA
Brand or Logo	AOZ or customer brand
Place of Origin	China, Zhejiang
Product Name	AOZ High Quality Front Wheel Hub Auto Part Wheel Hub Unit
Packing	White Box / Colour Box / Customized
Certification	ISO/TS16949 - 2016
Sample	Available
Delivery	Sea / Air / Land / Express
Supply Ability	10000 Piece / Per Month
Port	Shanghai, Ningbo, Yiwu, Guangzhou
ABS Sensor	Yes

ACCURACY SPECIFICATIONS
Bearing materials	GCr15 = SAE52100
Flange materials	55# Steel (High quality)
Ball / roller materials	GCr15 = SAE52100
Cage materials	Top Grade PA66 + GF25
Seal materials	Stainless steel + NBR
Wheel stud grade	10.9
Bearing rings hardness control	60-66 HRC
Ball / roller hardness control	61-66 HRC
Inner and outer ring race max roughness control	≤0.20μm
Inner and outer ring race max roundness control	≤3μm
Product inspection	100%
Quality Guarantee	2 years or 60,000 Kilometers

FAQs

Q1: What happens if I over-torque the axle nut?

A: Over-torquing crushes the internal bearing rollers and races, eliminating the necessary clearance. This creates extreme friction and heat, which will cause the new hub to fail very quickly. Always use a calibrated torque wrench.

Q2: How do I know if the noise is coming from the tire or the hub?

A: Tire noise usually sounds rhythmic and changes with the tread pattern. A failing hub produces a continuous humming or growling noise that increases in pitch and volume as vehicle speed increases, regardless of the road surface.

Q3: Can a worn hub assembly damage my CV axle?

A: Yes. If the hub has severe lateral play, the constant wobbling puts excessive stress on the CV axle splines and joints, potentially causing the axle to wear out or fail prematurely.

"Quality First, Customers First", "AOZ" committed to providing reliable products and long-term support to help our partners succeed.
